The CBC ECO threading heads at a glance
The ECO threading heads are supplied complete with chasers; each head cuts one thread size. The same heads are used in the ratchet of the FM-ECO hand pipe threader and on the portable threading machines.
CBC offers BSPT right-hand heads from 1/4″ to 2″ and NPT right-hand heads from 3/8″ to 2″. The heads up to 1″1/4 also fit the 114 MINI; the 1″1/2 and 2″ heads are intended for the FM-ECO and the F2-E. The 1/4″ and 3/8″ heads as well as the NPT heads are listed by CBC as options for the 114 MINI and the F2-E.
Technical Data
| Suitable for | FM-ECO (all sizes), 114 MINI (up to 1″1/4), F2-E (up to 2″) |
|---|---|
| Threads | BSPT right-hand 1/4″–2″; NPT right-hand 3/8″–2″ |
| Delivery | complete with chasers |
ECO threading heads BSPT (right-hand)
| Version | Article no. | Suitable for |
|---|---|---|
| BSPT 1/4″ | 000850 | FM-ECO, 114 MINI, F2-E |
| BSPT 3/8″ | 000851 | FM-ECO, 114 MINI, F2-E |
| BSPT 1/2″ | 000852 | FM-ECO, 114 MINI, F2-E |
| BSPT 3/4″ | 000853 | FM-ECO, 114 MINI, F2-E |
| BSPT 1″ | 000854 | FM-ECO, 114 MINI, F2-E |
| BSPT 1″1/4 | 000855 | FM-ECO, 114 MINI, F2-E |
| BSPT 1″1/2 | 000856 | FM-ECO, F2-E |
| BSPT 2″ | 000857.1 | FM-ECO, F2-E |
ECO threading heads NPT (right-hand)
| Version | Article no. | Suitable for |
|---|---|---|
| NPT 3/8″ | 000891 | FM-ECO, 114 MINI, F2-E |
| NPT 1/2″ | 000892 | FM-ECO, 114 MINI, F2-E |
| NPT 3/4″ | 000893 | FM-ECO, 114 MINI, F2-E |
| NPT 1″ | 000894 | FM-ECO, 114 MINI, F2-E |
| NPT 1″1/4 | 000895 | FM-ECO, 114 MINI, F2-E |
| NPT 1″1/2 | 000896 | FM-ECO, F2-E |
| NPT 2″ | 000897 | FM-ECO, F2-E |
CBC threaders for the ECO heads
The ECO heads fit:
